| Model | Capacity (m³) | Motor Power (kW) | Agitator Speed (rpm) | Tank Thickness (mm) | Operating Pressure (MPa) |
|---|---|---|---|---|---|
| WACSTR-500 | 0.5 | 2.2 | 0–120 | 6 | 0.3 |
| WACSTR-1000 | 1 | 3 | 0–120 | 8 | 0.3 |
| WACSTR-2000 | 2 | 4 | 0–100 | 10 | 0.3 |
| WACSTR-3000 | 3 | 5.5 | 0–100 | 12 | 0.3 |
| WACSTR-5000 | 5 | 7.5 | 0–80 | 14 | 0.3 |
| WACSTR-10000 | 10 | 11 | 0–80 | 16 | 0.3 |
Multiple reactor units can be connected in series to form a continuous reaction system.
The continuous stirred tank reactor (CSTR) is designed for continuous chemical reaction processes that require stable mixing and consistent product output. Unlike batch reactors, the CSTR allows reactants to be continuously fed into the reactor while products are simultaneously discharged, enabling steady-state production conditions.
The reactor is equipped with an efficient agitation system to ensure uniform mixing and stable reaction performance. Depending on process requirements, the system can include heating or cooling jackets, automated feeding and discharge systems, and PLC-based process control.
Continuous stirred tank reactors are widely used in chemical production, polymer synthesis, wastewater treatment, biochemical processes, and other continuous industrial operations.
Weang provides advanced continuous reactor solutions engineered for efficient industrial production. The Weang CSTR systems are designed with precision fabrication, reliable agitation technology, and flexible configuration options to meet diverse processing requirements.
With professional engineering support and customizable system integration, Weang continuous reactors help manufacturers achieve stable production, improved efficiency, and consistent product quality.
